The black line is a marking used to identify where one is allowed to walk on the wing without damaging the structure.  Stenciling would be adjacent to the line instructing 'Walkway Inboard' (at the wing root) or 'Walkway Forward' (along the wing leading edge).

Gun and ammunition access panels were secured with camlock fasteners similar to the 'Dzus' fasteners that hold the cowling on a Cessna.  Screws were used on most of the fillet section that covered the area where the wing joined the fuselage.

Look here:

Stenciling.  The dashed lines around the cannon bay are non-standard but you can see the camlock fasteners.



Screws on fillet section
